KOD |
inch |
L
mm |
a1
mm |
a2
mm |
b1
mm |
b2
mm |
g |
|
0431 03 0608 | 1/4″x5/16″ | 176 | 5.6 | 6 | 10 | 11.5 | 55 | 10 |
0431 03 0809 | 5/16″x3/8″ | 190 | 6.4 | 6.8 | 13 | 14.5 | 75 | 10 |
0431 03 0811 | 5/16″x7/16″ | 190 | 6.4 | 7.3 | 13 | 15.5 | 115 | 10 |
0431 03 0911 | 3/8″x7/16″ | 206 | 7.3 | 7.6 | 15.5 | 17 | 115 | 10 |
0431 03 1112 | 7/16″x1/2″ | 220 | 8.5 | 9 | 18.5 | 20 | 135 | 10 |
0431 03 1214 | 1/2″x9/16″ | 220 | 8.5 | 9.5 | 18.5 | 21.5 | 145 | 10 |
0431 03 1415 | 9/16″x19/32″ | 236 | 9.5 | 10 | 21.5 | 23 | 165 | 10 |
0431 03 1416 | 9/16″x5/8″ | 236 | 9.5 | 10 | 21.5 | 23 | 165 | 10 |
0431 03 1517 | 19/32″x11/16″ | 250 | 10.8 | 11.5 | 25 | 26.5 | 210 | 10 |
0431 03 1920 | 3/4″x25/32″ | 271 | 12 | 12.5 | 27.5 | 29 | 270 | 10 |
0431 03 2325 | 15/16″x1″ | 331 | 14.2 | 14.6 | 36.5 | 39.5 | 495 | 5 |
0431 03 3033 | 1 3/16″x1 5/16″ | 371 | 16.4 | 16.7 | 45 | 48 | 670 | 5 |
ÖZEL SERİLER | ||||||||
* 0431 03 1217 | 1/2″x11/16″ | 250 | 9 | 10 | 20 | 26.5 | 185 | 10 |
* 0431 03 1417 | 9/16″x11/16″ | 250 | 9.5 | 11.5 | 21.5 | 26.5 | 185 | 10 |
* 0431 03 1617 | 5/8″x11/16″ | 250 | 10.8 | 11.5 | 25 | 26.5 | 210 | 10 |
* 0431 03 1619 | 5/8″x3/4″ | 271 | 11.5 | 12.5 | 26.5 | 29 | 270 | 10 |
* 0431 03 2021 | 25/32″x13/16″ | 291 | 12.9 | 13.5 | 30.5 | 33 | 270 | 5 |
* 0431 03 1922 | 3/4″x7/8″ | 291 | 12.9 | 13.5 | 30.5 | 33 | 400 | 5 |
* 0431 03 2223 | 7/8″x15/16″ | 321 | 13.5 | 14.2 | 33 | 36.5 | 400 | 5 |
* 0431 03 2328 | 15/16″x1 1/8″ | 331 | 14.2 | 15 | 36.5 | 40.5 | 500 | 5 |
* 0431 03 2528 | 1″x1 1/8″ | 352 | 14,5 | 15.5 | 38 | 42.5 | 570 | 5 |
* 0431 03 3036 | 1 3/16″x1 3/8″ | 402 | 16.4 | 17.5 | 45 | 53 | 880 | 5 |
* 0431 03 3236 | 1 1/4″x1 7/16″ | 402 | 16.7 | 17.5 | 48 | 53 | 890 | 5 |
* 0431 03 3641 | 1 7/16″x1 5/8″ | 438 | 17.5 | 19.5 | 53 | 61 | 1100 | 5 |
* 0431 03 4146 | 1 11/16″x1 7/8″ | 485 | 19.5 | 20.5 | 61 | 67.5 | 1390 | 5 |
* 0431 03 4650 | 1 13/16″x2″ | 535 | 20.5 | 22.5 | 67.5 | 73.5 | 1955 | 5 |
